Static Mixer

• Material: Polypropylene (casing), Polyacetal (mixing elements)
• Color: Natural outer casing, Blue internal mixing elements
• Inner Diameter: 13.0 mm
• Outer Diameter: 14.0 mm
• Length: 293 mm
• Nozzle Tip Diameter: 4.0 mm
• Number of Mixing Elements: 24
• Retaining Method: 15.9 mm bell mouth connection
• Material Volume Capacity: 27.0 ml
• Maximum Pressure Capacity: 17 BAR (246 PSI)

The Static Mixer Nozzle 13-24 White is a high-quality, disposable mixing nozzle designed specifically for precise and consistent mixing applications. Crafted for adhesive dispensing systems, it features a bell mouth connection at the entry end, seamlessly fitting over metering machine exit manifolds. Its inner static mixing elements are made from high-strength polyacetal, ensuring optimal durability and resistance to high pressures, while the outer casing is constructed from sturdy polypropylene.

Key Features:

• Efficient Mixing: Equipped with 24 precision mixing elements, this static mixer guarantees homogeneous blending, ideal for 1:1 and 2:1 adhesive ratios.
•
• High-Quality Construction: The durable polyacetal elements and polypropylene housing withstand high pressures, making it highly reliable for continuous use.
•
• Bell Connection: Securely connects to metering and mixing machines, providing a leak-proof, stable fit during operation.
•
• Stepped Tip Design: The nozzle’s stepped tip design ensures precise application, reducing material waste and promoting cleaner dispensing.

Applications:

• Adhesive Dispensing: Effective in various adhesive applications requiring precision mixing, especially for 1:1 and 2:1 adhesives.
•
• Metering and Mixing Systems: Ideal for machines used in industries where consistent material blending is critical, such as construction, automotive, and manufacturing sectors.
•

The 13-24 Static Mixer Nozzle is engineered for high-performance adhesive mixing, delivering precise, reliable, and efficient res
